In store stocks availability are subject to respective retailers.
| AW10CDA4DI-5VN | AW13CDA4DI-5VN | AW18CDA4DI-5VN | AW24CDA4DI-5VN | |||
| Cooling Capacity (W) | 2800(300-3500) | 3600(800-4000) | 5350(1300-5400) | 6350(1800-7400) | ||
| Cooling Capacity (BTU/hr) | 9500 | 12300 | 18200 | 21600 | ||
| Rated Power Consumption (W) | 740(100-1350) | 1080(300-1700) | 1650(500-2200) | 1850（230-2500） | ||
| Energy Star level | 5 | 5 | 5 | 5 | ||
| CSPF Cooling (W/W) | 5.86 | 5.62 | 5.41 | 5.27 | ||
| Rated Running Current (A) | 3.6(0.6-6.0) | 5.5(1.5-7.5) | 8.2(2.3-9) | 8.0(1-11) | ||
| Power supply (Ph/V/Hz) | 1/220-240/50 | |||||
| Air flow volume (m3/h) | 650/570/520/470 | 680/610/580/530 | 950/800/700/600 | 1300/1200/1010/870 | ||
| Refrigerant | R32 | |||||
| Indoor Noise level (dB) | 39/36/32/28/22 | 40/37/33/29/23 | 46/41/38/36/24 | 52/48/44/40 | ||
| Outdoor Noise level (dB) | 49 | 50 | 52 | 56 | ||
| Stop Valve | Liquid Valve | DG4 | ||||
| Gas Valve | DG8 | DG10 | ||||
