Voice Control
Enjoy seamless voice control of your air conditioner,anytime, without the need for an internet connection.
Wi-Fi Control
Control your air conditioner anytime, anywhere, even when you are not at home.
Ai Eco (For 09K & 12K BTU only)
Powered by Huawei HiSilicon technology and a self-learning algorithm, AI ECO automatically adapts operation to help save up to 40% energy*. *Data source: AUX Air Conditioner Laboratory. Results may vary depending on installation conditions and usage. Comparison between the AUX CD Series 1.0 HP AI ECO model and the 1.0 HP Non-AI ECO model, cooling mode only. Test conditions: Outdoor temperature: 35°C; indoor temperature: 27°C; set temperature: 22°C. Total energy consumption was measured over the first 8 hours, with readings recorded every hour.
9500/12400/18500/24900 Btu/h (rated)
| Specification | Unit | AW09CDB4DI-3 | AW12CDB4DI-3 | AW18CDB4DI-3 | AW24CDB4DI-3 |
| Rated Capacity (Cooling) | W | 2700 | 3500 | 5300 | 7100 |
| Rated Capacity (Cooling) | BTU/hr | 9500 | 12400 | 18500 | 24900 |
| Rated Power Consumption | W | 620 | 960 | 1260 | 1900 |
| Rated Running Current | A | 3 | 4.5 | 5.9 | 8.5 |
| SEER | BTU/W.h | 21.56 | 21.56 | 21.56 | 21.56 |
| Energy Efficiency Star Rating |  |
 |
 |
 |
|
| Power Supply | Ph/V/Hz | 1/220-240/50 | 1/220-240/50 | 1/220-240/50 | 1/220-240/50 |
| Air Direction | Up-Down-Left-Right Auto Swing | Up-Down-Left-Right Auto Swing | Up-Down-Left-Right Auto Swing | Up-Down-Left-Right Auto Swing | |
| Liquid Pipe | mm | 6.35 (1/4") | 6.35 (1/4") | 6.35 (1/4") | 6.35 (1/4") |
| Gas Pipe | mm | 9.52 (3/8") | 9.52 (3/8") | 12.7 (1/2") | 15.88 (5/8") |
| Indoor Unit Weight (Net) | Kg | 8.5 | 8.5 | 13.5 | 14 |
| Evaporator Tube Material | Copper | Copper | Copper | Copper | |
| Evaporator Fin Material | Hydrophilic foil | Hydrophilic foil | Hydrophilic foil | Hydrophilic foil | |
| Noise (Indoor) | dB | 38/35/32/23 | 38/35/32/23 | 47/43/38/26 | 48/44/40/26 |
| Net Dimension (Indoor W×H×D) | mm | 834×214×298 | 834×214×298 | 1145×244×331 | 1145×244×331 |
| Packing Dimension (Indoor W×H×D) | mm | 895×300×371 | 895×300×371 | 1207×342×403 | 1207×342×403 |
| Compressor Type | Rotary | Rotary | Rotary | Rotary | |
| Refrigerant | R32 | R32 | R32 | R32 | |
| Refrigerant Charged | g | 450 | 500 | 880 | 1250 |
| Outdoor Unit Weight (Net) | Kg | 21.5 | 23 | 38.5 | 40.5 |
| Condenser Tube Material | Copper | Copper | Copper | Copper | |
| Noise (Outdoor) | dB | 45 | 48 | 55 | 56 |
| Net Dimension (Outdoor W×H×D) | mm | 709×280×536 | 709×280×536 | 900×350×700 | 900×350×700 |
| Packing Dimension (Outdoor W×H×D) | mm | 825×345×595 | 825×345×595 | 1015×425×762 | 1015×425×762 |
